The electric welder uses the principle of inductance. When the inductance is turned on and off, it will produce a huge voltage change. The high-voltage arc generated by the positive and negative poles in the instantaneous short-circuit will melt the solder on the electrode to make them atomically bonded. purpose. The core IGBT products are stable, reliable, cost-effective, and can provide differentiated solutions to solve customers' pain points.
|
Electrical Welder Optional Device
|
|
Package
|
Voltage
|
current
|
Topology
|
|
TO-247
|
600V
|
40A
|
Single-tube
|
|
600V
|
50A
|
Single-tube
|
|
1200V
|
25A
|
Single-tube
|
|
1200V
|
40A
|
Single-tube
|
|
TO-264
|
1200V
|
40A
|
Single-tube
|
|
C1 module
|
1200V
|
75A
|
Two unit module
|
|
1200V
|
100A
|
Two unit module
|
|
Aluminum plate
|
Replacement of insulating gaskets, high production efficiency and low thermal resistance
|
